Experiencing issues connecting OBS Studio to LiveKit can be frustrating, but with a systematic approach, you can identify and resolve the problems. This article provides a comprehensive guide to troubleshooting OBS connection issues with LiveKit, focusing on common configuration errors, network issues, and other potential roadblocks. We'll delve into the specifics of setting up livekit-ingress and livekit-server, interpreting logs, and ensuring OBS Studio is correctly configured for seamless streaming. Whether you're encountering session closures, connection errors, or Redis-related issues, this guide will equip you with the knowledge and steps to get your live streams up and running smoothly. Let's dive in and get your LiveKit OBS connection sorted out!

Understanding the Configuration

To successfully connect OBS Studio to LiveKit, it's crucial to understand the configurations of both livekit-ingress and livekit-server. These components work in tandem to facilitate real-time media streaming. The livekit-ingress acts as the entry point for your stream, receiving the RTMP feed from OBS Studio and forwarding it to the livekit-server. The livekit-server then handles the distribution of the stream to connected clients. Let's break down the configurations provided and identify potential areas for misconfiguration.

Analyzing livekit-ingress Configuration

The provided livekit-ingress configuration snippet reveals several key parameters that govern its behavior. It's essential to ensure these parameters are correctly set to avoid connection issues. Here’s a detailed look:

api_key: key1
api_secret: secret2
ws_url: ws://livekit-server:7880

redis:
 address: redis:6379
 username: admin
 password: admin
 db: 0
 use_tls: false
 max_redirects: null

rtmp_port: 1935
whip_port: 8080
http_relay_port: 9090

logging:
 json: false
 level: debug

development: true
rtc_config:
 udp_port: 7885
 use_external_ip: true
 enable_loopback_candidate: false
  • API Key and Secret: The api_key and api_secret are crucial for authentication. These credentials must match the corresponding keys configured in the livekit-server. Mismatched keys will prevent OBS Studio from establishing a connection. Ensure key1 and secret2 are correctly paired and present in the server configuration.
  • WebSocket URL (ws_url): This URL specifies the address where livekit-ingress connects to the livekit-server for signaling. The value ws://livekit-server:7880 indicates that livekit-ingress is trying to connect to livekit-server on port 7880. If livekit-server is running in a different container or on a different network, the hostname livekit-server might not resolve correctly. You should verify that DNS resolution within your Docker network is functioning or use the IP address of the livekit-server container directly.
  • Redis Configuration: The Redis section defines the connection parameters for the Redis instance used for storing state and coordinating between livekit-ingress and livekit-server. The address, username, password, and db settings must accurately reflect your Redis setup. The provided credentials (admin/admin) are often defaults and should be changed for production environments. A failure to connect to Redis can lead to various issues, including the inability to retrieve ingress information, as seen in the logs.
  • Ports: The rtmp_port, whip_port, and http_relay_port specify the ports on which livekit-ingress listens for RTMP, WHIP, and HTTP relay connections, respectively. The rtmp_port (1935) is particularly relevant for OBS Studio, which typically uses RTMP for streaming. Ensure that this port is accessible from the network where OBS Studio is running and that there are no firewall rules blocking the connection.
  • Logging: The logging section configures the logging behavior of livekit-ingress. Setting level to debug provides detailed logs, which are invaluable for troubleshooting. If you encounter issues, examining the logs will often reveal the root cause. The json: false setting means logs are in plain text, making them easier to read.
  • Development Mode: The development: true setting enables development-specific features and configurations. While useful for local testing, it's generally not recommended for production deployments due to potential security and performance implications.
  • RTC Configuration: The rtc_config section configures the Real-Time Communication (RTC) settings. Setting use_external_ip: true instructs LiveKit to use the external IP address of the server, which can be problematic if the server is behind a NAT. This is a common cause of connection issues, as the server might advertise an IP address that is not reachable from the client's perspective. Additionally, enable_loopback_candidate: false disables the use of loopback addresses, which can further complicate connectivity in certain network setups. It's recommended to carefully consider your network topology and adjust these settings accordingly. If you're running in a containerized environment, you might need to ensure that the container's ports are properly exposed and that the container can resolve its external IP address.

Analyzing livekit-server Configuration

Similarly, the livekit-server configuration needs careful examination to ensure it's correctly set up to handle incoming streams. Let's dissect the provided configuration snippet:

port: 7880

redis:
 address: redis:6379
 username: admin
 password: admin
 db: 0

rtc:
 port_range_start: 5000
 port_range_end: 5010
 tcp_port: 7881
 use_external_ip: false
 enable_loopback_candidate: false

keys:
 key1: secret1

logging:
 level: info

room:
 max_participants: 10
 enabled_codecs:
 - mime: audio/opus
 - mime: video/vp8
 enable_remote_unmute: true

turn:
 enabled: false

ingress:
 rtmp_base_url: rtmp:///localhost:1935/live
 whip_base_url: http://livekit-ingress:8080/w
  • Port: The port setting (7880) specifies the port on which livekit-server listens for incoming connections. This port must match the port specified in the ws_url of the livekit-ingress configuration. If these ports don't align, livekit-ingress won't be able to connect to livekit-server.
  • Redis Configuration: Just like in livekit-ingress, the Redis configuration in livekit-server must correctly point to your Redis instance. The same credentials (admin/admin) are used here, and any connection issues with Redis will prevent livekit-server from functioning correctly. The error
