Hey guys! 👋 Let's dive into enabling draggable data points in your ScottPlot.WPF applications. You've probably stumbled upon the coolness of interactive plots and want to make those data points dance to your tune, right? Well, you're in the right place! This article will guide you through implementing point dragging in ScottPlot.WPF, especially if you've been wrestling with the update from older versions.

Understanding the Challenge

It looks like you're aiming to implement draggable points in your WPF application using ScottPlot.WPF, which is awesome! You've even found the PR #1560 (New plottable: ScatterPlotDraggable), suggesting you're on the right track. However, things have shifted a bit since the move to ScottPlot 5.0.55. The challenge now is figuring out how to achieve the same draggable functionality with the latest API.

Quick Recap

  • Goal: Make points on a Scatter plot draggable in ScottPlot.WPF.
  • Context: Using ScottPlot.WPF v5.0.55 in a WPF (.NET 9) application with an MVVM pattern.
  • Problem: Older examples (like PR #1560) are based on previous versions, and the ScatterDraggable class might not be directly available or implemented the same way in the latest version.

Let's break down how to get those points moving!

Diving into ScottPlot 5 and Draggable Points

In ScottPlot 5, the approach to handling interactive plots and draggable elements has evolved. The good news is that the functionality you're seeking is definitely achievable, but it requires a slightly different implementation than in earlier versions. ScottPlot 5 leverages events and customizations to provide interactive features.

The Core Idea

Instead of a direct ScatterDraggable plot type, you’ll be working with the standard Scatter plot and adding interactivity through event handling and custom logic. This approach gives you more control and flexibility over how the dragging behavior is implemented.

Key Components

  1. Scatter Plot: The foundational plot type for displaying your data points.
  2. Mouse Events: Handling mouse events (like MouseDown, MouseMove, MouseUp) on the plot control to detect dragging actions.
  3. Hit Testing: Determining which data point is closest to the mouse cursor during a drag.
  4. Point Manipulation: Updating the data point's position based on mouse movement.
  5. Plot Refresh: Redrawing the plot to reflect the changes.

Step-by-Step Implementation Guide

Alright, let's get our hands dirty with some code! Here’s a step-by-step guide to implementing draggable points in your ScottPlot.WPF application.

Step 1: Setting Up Your Project

First, ensure you have the latest ScottPlot.WPF package installed in your project. Since you're already using version 5.0.55, you should be good to go. If not, you can add it via NuGet Package Manager:

Install-Package ScottPlot.WPF

Step 2: Creating the Scatter Plot

In your ViewModel (or code-behind, depending on your architecture), create your scatter plot as you’ve already done. This involves creating the WpfPlot control and adding a Scatter plot to it.

using ScottPlot;
using ScottPlot.Plottables;
using ScottPlot.WPF;
using System.Collections.ObjectModel;
using System.ComponentModel;
using System.Runtime.CompilerServices;
using System.Windows;
using System.Windows.Input;

namespace ColdAtomPulseGen.ViewModels.Pages
{
    public partial class DashboardViewModel : ObservableObject, INavigationAware
    {
        private bool _isInitialized = false;

        [ObservableProperty]
        WpfPlot plotControl = new();

        private Scatter? scatterPlot;
        private int draggedIndex = -1;
        private double[] dataX = { 0, 4, 4, 4.5, 4.5 };
        private double[] dataY = { 3.2, 3.2, 10, 10, 0 };

        public Task OnNavigatedToAsync()
        {
            if (!_isInitialized)
            {
                Plot();
                _isInitialized = true;
            }

            return Task.CompletedTask;
        }

        void Plot()
        {
            scatterPlot = PlotControl.Plot.Add.Scatter(dataX, dataY);
            PlotControl.Plot.XLabel("Time (sec)");
            PlotControl.Plot.YLabel("Voltage (V)");

            PlotControl.MouseDown += PlotControl_MouseDown;
            PlotControl.MouseMove += PlotControl_MouseMove;
            PlotControl.MouseUp += PlotControl_MouseUp;

            PlotControl.Refresh();
        }

        private void PlotControl_MouseDown(object sender, MouseButtonEventArgs e)
        {
            (double x, double y) = PlotControl.GetMouseCoordinates();
            double tolerance = 10; // Adjust as needed
            (double pointX, double pointY, int index, double distance) = scatterPlot.GetPointNearest(new PixelPosition(x, y));

            if (distance < tolerance)
            {
                draggedIndex = index;
            }
            else
            {
                draggedIndex = -1;
            }
        }

        private void PlotControl_MouseMove(object sender, MouseEventArgs e)
        {
            if (draggedIndex >= 0)
            {
                (double x, double y) = PlotControl.GetMouseCoordinates();
                dataX[draggedIndex] = x;
                dataY[draggedIndex] = y;

                scatterPlot.Update(dataX, dataY);
                PlotControl.Refresh();
            }
        }

        private void PlotControl_MouseUp(object sender, MouseButtonEventArgs e)
        {
            draggedIndex = -1;
        }

        public Task OnNavigatedFromAsync() => Task.CompletedTask;
    }
}

<Page
    x:Class="ColdAtomPulseGen.Views.Pages.DashboardPage"
    xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
    xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
    xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
    xmlns:local="clr-namespace:ColdAtomPulseGen.Views.Pages"
    xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
    xmlns:ui="http://schemas.lepo.co/wpfui/2022/xaml"
    Title="DashboardPage"
    d:DataContext="{d:DesignInstance local:DashboardPage, IsDesignTimeCreatable=False}"
    d:DesignHeight="450"
    d:DesignWidth="800"
    ui:Design.Background="{DynamicResource ApplicationBackgroundBrush}"
    ui:Design.Foreground="{DynamicResource TextFillColorPrimaryBrush}"
    Foreground="{DynamicResource TextFillColorPrimaryBrush}"
    xmlns:ScottPlot="clr-namespace:ScottPlot.WPF;assembly=ScottPlot.WPF"
    mc:Ignorable="d"
>

    <Grid>
        <Grid.RowDefinitions>
            <RowDefinition Height="Auto"/>
            <RowDefinition Height="*" />
        </Grid.RowDefinitions>

        <TextBlock Grid.Row="0" Text="Digital Waveform" FontSize="24" Margin="12"/>

        <ContentControl Grid.Row="1" Content="{Binding ViewModel.PlotControl, Mode=OneTime}"/>
    </Grid>
</Page

In this code:

  • We store the Scatter plot as a field (scatterPlot) so we can access it later.
  • We keep track of the index of the dragged point using draggedIndex. If no point is being dragged, it’s -1.
  • dataX and dataY hold the data point values.

Step 3: Handling Mouse Events

This is where the magic happens! You'll need to handle the MouseDown, MouseMove, and MouseUp events on your PlotControl.

MouseDown Event

When the mouse button is pressed, you need to determine if the mouse cursor is close to a data point. If it is, record the index of that point.

private void PlotControl_MouseDown(object sender, MouseButtonEventArgs e)
{
    (double x, double y) = PlotControl.GetMouseCoordinates();
    double tolerance = 10; // Adjust as needed
    (double pointX, double pointY, int index, double distance) = scatterPlot.GetPointNearest(new PixelPosition(x, y));

    if (distance < tolerance)
    {
        draggedIndex = index;
    }
    else
    {
        draggedIndex = -1;
    }
}

Here’s what’s going on:

  • PlotControl.GetMouseCoordinates() gets the plot coordinates of the mouse position.
  • tolerance defines how close the mouse needs to be to a point for it to be considered a “hit.”
  • scatterPlot.GetPointNearest finds the closest data point to the mouse cursor.
  • If the distance is within the tolerance, we set draggedIndex to the index of the point; otherwise, we set it to -1.

MouseMove Event

While the mouse is moving, check if a point is being dragged (draggedIndex != -1). If so, update the data point's position and refresh the plot.

private void PlotControl_MouseMove(object sender, MouseEventArgs e)
{
    if (draggedIndex >= 0)
    {
        (double x, double y) = PlotControl.GetMouseCoordinates();
        dataX[draggedIndex] = x;
        dataY[draggedIndex] = y;

        scatterPlot.Update(dataX, dataY);
        PlotControl.Refresh();
    }
}

Key points:

  • We get the new mouse coordinates.
  • We update the dataX and dataY arrays with the new coordinates for the dragged point.
  • scatterPlot.Update efficiently updates the plot with the new data.
  • PlotControl.Refresh() redraws the plot.

MouseUp Event

When the mouse button is released, reset draggedIndex to -1 to stop the dragging.

private void PlotControl_MouseUp(object sender, MouseButtonEventArgs e)
{
    draggedIndex = -1;
}

Step 4: Wiring Up the Events

Make sure to subscribe to these events when you initialize your plot. Add these lines in your Plot() method:

PlotControl.MouseDown += PlotControl_MouseDown;
PlotControl.MouseMove += PlotControl_MouseMove;
PlotControl.MouseUp += PlotControl_MouseUp;

Putting It All Together

Here's a complete example combining all the steps:

Pro Tips and Considerations

Optimization

For plots with a large number of data points, consider optimizing the GetPointNearest call. You might explore spatial indexing techniques or other optimizations to improve performance.

Customization

Feel free to customize the appearance of the dragged point. For example, you could change its color or size while it’s being dragged to provide visual feedback to the user.

Error Handling

Add error handling to prevent issues if the data arrays are modified from other threads or if the plot is disposed of while a drag operation is in progress.

Data Binding

If you're using MVVM, ensure that your data arrays (dataX and dataY) are observable. This way, changes to the data will automatically reflect in your UI. You might use ObservableCollection<T> or implement INotifyPropertyChanged.

Conclusion

So there you have it! Enabling draggable data points in ScottPlot 5 might seem a bit different from older versions, but it’s totally doable. By handling mouse events and manipulating your data, you can create interactive plots that respond to user input. Keep experimenting with these techniques, and you’ll be able to build some seriously cool applications with ScottPlot!

I hope this guide was helpful, guys. Happy plotting! 🚀
